Uflex Uc128Ts-1 Hydraulic Cylinder – Version 1 Replacement For Marine Steering Systems [Uc128Ts-1]

Description

UC128 Version 1 Hydraulic Cylinder

Compatible with competing helms, hoses, and oil, the UC128 cylinder is built to last with heavy-duty stainless steel cylinder rods, seals, and link assemblies. Constructed of top-grade materials this cylinder is simple to install and fits almost every two and four-stroke outboard engine in the market.

Balanced: The number of turns lock-to-lock is equal port to starboard or vice-versa. High resistance stainless steel connection bolt.

• Volume: 120cc: 7.3 cu. in
• Output Force: 450 kg – 992 lbs
• Inside Diameter: 35mm – 1.37″
• Stroke: 185mm – 7.28″
• 3/8″ (9,5 mm fittings) – For high pressure flex hose
• Bleed Fittings: DN5 Quick connect
